Intro to Nanocrystalline Core for High Frequency Transformer TRANSMART
Unlike ferrite magnetic cores, the shape of nanocrystalline alloy thin strip magnetic cores in their free state is prone to deformation. When such deformation occurs, the magnetic properties deteriorate sharply. Therefore, it is necessary to skeleton or install protective boxes on the surface of nanocrystalline alloy soft magnetic cores for protection. Installing the magnetic core into a closed protective box or using surface spraying or electrostatic spraying to form a resin or plastic protective layer is a conventional protection method. Another solution is to wrap the outer surface of the magnetic core with glass fiber and add an epoxy resin layer.During the entire process of using nanocrystalline magnetic rings (ultra microcrystalline iron cores) in inverter power supplies, there have been some problems such as noise, ductility, consistency, etc. These problems have already been gradually addressed. High power inverters and switching power supplies have developed relatively mature and are widely used in various fields. They have the advantages of small size, high efficiency, energy conservation and environmental protection. At present, it has been widely used in industries such as inverter welding machines, power systems, electroplating process electrolysis power supplies, induction heating equipment, charging power supplies, etc., and there will be even greater improvements in the next two years.Features:High saturation magnetic induction intensityHigh magnetic conductivityHigh permeabilityLow coercivityLow remanenceLow core lossGood temperature stabilityCompact sizeEmail: firstname.lastname@example.org Make sure to get notified: Check my website: https://www.transmart.netAdd me on Facebook: https://www.facebook.com/Transmart.Ind.Ltd Add me on Youtube: https://www.youtube.com/c/TransmartIndustrialLtdAdd me on LinkedIn: https://www.linkedin.com/company/transmart-industrial-limited/ Everything you wanted to know please contact us immediately if you are interested in.
Professional Toroidal core chamfered manufacturers
Chamfered toroidal core also called edge-grinded toroidal core.Tape wound toroidal cores are with right-angled edges, which are very sharp and dangerous.The sharp edges will cut through insulation tapes and damage copper wires wound on the core.Transmart uses CNC machines to chamfer toroidal cores according to customer requests, radius from 1mm to 5mm, smooth edges finishing. Advantages of chamfer coresSmooth round edgesProtect insulation tapeProtect copper wiresShorter coil length ( less copper used, save money)
Instrument Transformer Cores Custom Wound Cores
INSTRUMENT TRANSFORMER CORESTransmart Industrial manufacturer tape wound cores for current transformers and voltage transformers with the following materials:Grain oriented silicon steels: Thickness of 0.05mm, 0.08mm, 0.10mm, 0.20mm, 0.23mm, 0.27mm, 0.30mm and 0.35mm. Material width 5mm minimum.VARIOUS SHAPE CORES AVAILABLEToroidal core, oval core, rectangular core, cross-section core C cut core, Gap core.
Intro to Iron-based Amorphous Filter Inductor Cores TRANSMART
Fe-based amorphous core filter inductanceFe-based amorphous filter inductor core having excellent frequency characteristics and the DC superposition characteristic and a low core loss, and its permeability can be controlledVary within a wide range (u a 120-1200), may be resistant to different ranges of ampere-turns of bias (bias magnetic field), it is suitable for various high-frequency, alternating and direct superimpositionInductive application device, which is cost-effective than molybdenum and iron-nickel Sendust magnetic core.Applications· Car Audio choke· PFC correction inductor· A differential mode filter and a smoothing filter output· DC / DC converter filter coil· Conventional filter coil and the filter coil adapter FeaturesHigh saturation magnetic induction, low coercivity, low loss;Excellent anti-DC bias characteristic;High permeability from 120 to 1200, number of turns less.
Transmart core, one-stop solutions for magnetic cores and transformers.
As one of the leading transformer core manufacturers in China, We definitely see ourselves as the soft magnetic material & toroidal transformer service provider. We also provide application solutions and value-added products to our customers. Our highly skilled operators produce common mode chokes, reactors, and electronic transformers of both high and low-frequency components for applications in photovoltaic inverters, electric vehicles, smart grids, telecommunications, power supplies, and more.
Welcome to Transmart industrial limited, one of the leading magnetic core manufacturers in China.
We are a group company located in Foshan, China, with two manufacturing plants, the magnetic core & transformer production plants covers more than 70,000Sqare meters. We specialized in a broad range of tape wound cores in amorphous metal materials, nanocrystalline alloys, silicon steel core, and mu-metal Nickel alloys, for a wide variety of applications including solar inverters, new energy vehicles, instrument transformers, current sensors, common mode chokes, power supplies transformers. Our main products including soft magnetic materials and toroidal transformers. We also manufacture high-performance components using our high-quality cores made in-house.
One of the key factors to the success of TRANSMART is focusing on basic raw materials research and development. Our ability to tailor the composition and specific heat treatments according to our know-how enables us to design alloys with unique properties for specific customer needs.
Transmart is one of the few companies worldwide that have mastered the rapid solidification process where alloys are being produced as a thin strip to its final thickness of typically 16 to 30 μm.
We tightly control all aspects of our processes. We do our own slitting. we are controlling our products from beginning to end with quality in mind.
The alloy ribbons of large coils are cut to the required sizes using specially developed precision coil slitting machines.
The small cores are wound into toroidal with fully automatic winding machines, while the big cores are wound by semi-automatic winding machines. There are 70 fully automatic winding stations and 30 semi-automatic winding machines at Transmart, with a capacity of winding 100K units per day.
The heat treatment or annealing process represents the cornerstone of the know-how acquired by Transmart. It is the key process that defines the properties of the final core. Some cores need magnetic field heat treatment in order to achieve the values designed. The annealing temperature is 500- 600 °C and the cycle time is longer than 10 hours. Throughout the process, fully automated oven controllers provide real-time monitoring of temperature, atmosphere, and cycle time.
One of the main products at Transmart is tape wound cut cores including C-cores, E-cores, gap cores, split cores, and customized cut cores. Both our plants have 60 high-precision cutting machines, with a capacity of 500,000 pieces per month, being one of the largest cut core manufacturers in China.
Following the annealing process, the cores are being encapsulated or coated to provide optimum protection against mechanic stress. Custom designed fully encapsulation lines shorten the manufacturing time. Cores can be encapsulated in the plastic case, metal case, and insulation materials.
At TRANSMART, every core we manufacture is made to our customer’s exact specification, our engineering system generates customized designs according to electrical, mechanical, and operating requirements. We are certified according to ISO9001, 14001 45001, and IATF16949. We built a state-of-the-art manufacturing facility for automotive products. Our commitment to quality can be seen at each stage of design and manufacturing. The fully automatic production ensures high-quality consistency and transparency. The cores are used in new energy vehicle electronic parts.
We definitely see ourselves as the service provider. We also provide application solutions and value-added products to our customers. Our highly skilled operators produce common mode chokes, reactors, and transformers of both high and low-frequency components for applications in photovoltaic inverters, electric vehicles, smart grids, telecommunications, power supplies, and more.
Thank you for visiting Transmart Industrial. I hope you are convinced that our technical and manufacturing capabilities can scale to meet your magnetic component needs. Whether your project calls for customization in small quantities or large scale production, in need of magnetic cores or components, we have the expertise and state-of-the-art equipment to satisfy your needs.
